JTAG-Booster for AMD élanSC520
2.6.Read an I2C-Device to file
Usage:
JTAGEL5 /RI2C filename /L=hhhhhh [optionlist]
The contents of a I2C-Device (i.e. a serial EEPROM) is read and written to a file.
The option /LENGTH= must be specified.
Options:
/DEVICE-BASE=hhhhhh 4
See function /PI2C (Chapter 2.5)
/OFFSET=hhhhhh
Reading of the I2C-Device starts at an offset of hhhhhh relative to the start
address of the I2C-Device.
Default:
Abbreviation:
/OFFSET=0
/O=
/LENGTH=hhhhhh
The number of read bytes must be specified otherwise an error message occurs.
Abbreviation:
/L=
hhhhhh=number base is hex
/I2CCLK=pin_name
See function /PI2C (Chapter 2.5)
/I2CDAT=pin_name
See function /PI2C (Chapter 2.5)
/I2CDATO=pin_name
See function /PI2C (Chapter 2.5)
/I2CDATI=pin_name
See function /PI2C (Chapter 2.5)
